Product Highlights-

• (4) 10/100 Fast Ethernet Ports
• 24V PoE Passthrough for airMAX CPE
• 802.11n, 2×2 MIMO Technology
• Up to 300 Mbps in the 2.4 GHz Radio Band
• Powered by 24V Passive PoE or 2A Micro USB Adapter (Not
Included)
Features:

FDimensions 87.80 × 89.50 × 89.25 mm
(3.46 × 3.52 × 3.51’)
Weight 215 g (7.58 oz)
Power Supply 5V
Power Method PoE 24V In on LAN Port 1 or
2A Micro USB Adapter (Not Included)
Supported Power Voltage 4.95-5.05V
Max. Power Consumption 5W
PoE Out Controllable 24V PoE Out (+4, 5; -7, 8) on WAN Port
Management Interface Wi-Fi / Ethernet
Networking Interface (4) 10/100 Fast Ethernet Ports
LED Status
Max. TX Power 22 dBm
Antenna Gain 4 dBi
Max. Speeds 300 Mbps
Enclosure Characteristics Black Plastic
ESD/EMP Protection ±24 kV RJ-45 Interface
Operating Temperature -10 to 50° C (-14 to 122° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC
